HELLA BATTERY MAIN CIRCUIT BREAKER 24V

Discover this robust battery switch for 24v. With this switch, you can switch off the entire electrical circuit of your truck with one hand movement. This prevents your battery from running empty and can also be used as protection against theft and fire. You can connect the battery switch from Hella both to the positive and negative battery source.



Features:

- Main circuit breaker

- Battery circuit breaker

- Voltage: 24V

- Current: 100A

- Peak power: 2500A (5sec)

- Mounting: screws

- Connection thread: M10

- Number of connections: 2

- Diameter: 23.5mm

- DIN / ISO: 40050

- DIN / ISO: IP53Hinten

- DIN / ISO: IPX4Vorne

- Fluidity: 1.5mm
